RCF SUB 8004-AS active subwoofer

Original price was: €2,150.Current price is: €1,550.

The 8004-AS is an incredibly powerful 18-inch subwoofer well suited for all professional applications. This active sub has an unparalleled 18-inch woofer with a 4-inch voice coil that can reach insanely low frequencies thanks to it birch housing. It’s amplified by a 1,250W digital amp module, and as such, this RCF Sub 8004-AS will deliver excellent performance in the most demanding of situations.

Functions on Board
This subwoofer has the digital amp module to thank for its power. The module works in a separate compartment so the module won’t have any issues with vibrations. The Sub 8004-AS also offers an array of options when it comes to both settings and functionality, has a variety of controls onboard for volume, time delay, high pass and more.

Flexible Settings
The RCF Sub 8004-AS is suited for stacking with the NXL23-A and NXL24-A, and you can be used as part of versatile setups with the HDL 10-A and HDL 20-A. Make use of the pole mount to add a satellite speaker, and enjoy the placement flexibility of this subwoofer, as you can position it either horizontally or vertically, thanks to the M20 pole mounts, which are fitted for use in both positions. Even the RCF logo turns with the sub!

Tips or comments about this product
Please note: the product delivered will vary slightly compared with the product in the picture.

Description

Specifications

Product features
Speaker connections XLR / TRS combi input, out / link / thru
Woofer diameter 18 inches
Weight per speaker 50 kg
Maximum SPL 130 dB – 139 dB
Maximum subwoofer frequency 120 Hz
Minimum frequency 20 – 21 Hz
RMS power in watts 750 – 1,499 W
Locking speaker connectors yes
Weight and dimensions including packaging
Weight (incl. packaging)51.5 kg
Dimensions (incl. packaging)77.0 x 75.0 x 61.0 cm
Product specifications
Active subwoofer
Peak power: 2,500 W
RMS capacity: 1,250 W
Maximum SPL: 136 dB
Frequency range: 30 Hz – 120 Hz
18-inch ventilated woofer with 4-inch voice coil
With 1,250 W amp module
DSP driven input section with presets
Integrated controls for volume, deep/punch switch, high pass, phase, cardioid and time delay
Crossover frequency: adjustable between 80 and 100 Hz
Protection: thermal, RMS
Limiter: fast limiter
Convection cooling for amp module
Signal input: XLR male
Signal output: XLR female
Input sensitivity: -2 dBu, +4 dB/u
Cabinet: Baltic birch wood
Equipped with 2x M20 pole mounts
Aluminium handles on each side
Sturdy wheels
Dimensions: 557.5 mm x 700 mm x 700 mm (W x H x D)
Weight: 51.0 kg
