Product features
19 inches yes
Number of auxiliaries 5 – 6
Number of microphone inputs 9 – 12
Number of mono channels 10
Number of stereo channels 4
Number of submasters 2
Phantom power yes
Headphone output yes
Built-in audio interface sold separately (via expansion card)
Built-in audio playe rno
Built-in effects no
Built-in mixer effects channel EQ
Insert connectors yes, only mono channels
Type of mixer inputs microphone input (XLR), balanced line input (TRS jack), unbalanced line input (RCA)
Type of mixer studio / PA mixer
Type of mixer outputs balanced line output (XLR), balanced line output (TRS jack), unbalanced line output (RCA), stereo headphone output (TRS jack or mini jack)
Volume control faders
Weight and dimensions including packaging
Weight (incl. packaging)5.0 kg
Dimensions (incl. packaging)63.0 x 60.0 x 33.0 cm
Product specifications
mixer
for live applications
mountable in 19-inch rack
10 mic/line inputs with balanced XLR/TRS jack, insert and direct
100mm faders
6 aux sends (pre/post fade switchable)
4 audio groups
2 dual stereo inputs with independent gain and ON switches
6×2 matrix
oscillator and pink noise generator
+48 V phantom power
signal and peak LEDs
talkback microphone input (XLR) with trim
lamp connector
possibility to build in optional USB interface
dimensions (WxDxH): 507 x 530 x 194 mm
weight: 13 kg
