HK Audio Linear 5 L5 115 FA active speaker 2x HK Audio Linear 5 L5 115 FA active speaker
The L5 115 FA speaker is fitted with a 15-inch woofer, 1-inch driver and a comprehensive 1000W amplifier module. The result is an impressive SPL, great tone and excellent versatility.
Product features
Bluetooth no
Tweeter diameter 1 inch
Woofer diameter 15 inches
Suitable as monitor yes
Weight per speaker 31 kg
Built-in equaliser no
Maximum SPL 130 dB – 139 dB
Maximum frequency 20 – 20.9 kHz
Minimum frequency 40 – 49 Hz
RMS power in watts 750 – 1,499 W
Analogue audio input type balanced line in (TRS jack), microphone input (XLR)
Analogue audio output type thru (XLR)
Passive speaker output no
Weight and dimensions including packaging
Weight (incl. packaging)33.7 kg
Dimensions (incl. packaging)73.6 x 50.2 x 44.5 cm
Product specifications
Powerful active speaker
Also suitable as a floor monitor
Frequency range (-3 dB): 57 to 18,000 Hz
Frequency range (-10 dB): 48 to 20,000 Hz
Sensitivity high: 110 dB full-space, 116 dB half-space
Sensitivity low: 100 dB full-space, 106 dB half-space
Maximum sound pressure at 10% distortion: 129 dB
Maximum sound pressure peak at 10% distortion: 139 dB
Maximum sound pressure in theory: 139 dB
Amplifier: class-D
Amplifier power: 1,000W
Power high: 350 watts at 4 ohms
Power low: 650 watts at 4 ohms
Protected from low power, thermal protection, short-circuit, too much power
Subsonic 24 dB/octave filter peak limiter
Power consumption: 3A at 230V
Connectors: 2x XLR in, 2x XLR through, 1x XLR Mix Out
Woofer: 1 inches with 3-inch coil
Driver: 1x 1-inch with 1,75-inch coil
Horn projection: 60 – 90 x 55 degrees, rotatable
Built-in crossover: 1,650 Hz, 24 dB/octave
Built-in flange: DuoTilt 3/7
Rigging points: 3x M8
Safety circuit with PTC and light
2 integrated handles
Rugged housing: birch plywood / MDF
Grill: 2mm steel grill with speaker foam on the inside
Scratch proof black lacquer
Dimensions: 449 x 708 x 450 mm
Weight: 30.7 kg
HK Audio Linear 5 L Sub 2000 A active subwoofer 4x HK Audio Linear 5 L Sub 2000 A active subwoofer
HK Audio’s L Sub 2000 A is a high-quality subwoofer. The speakers from the Linear 5 series are easy to chain, allowing you to create both small and large setups to suit any situation.
Product features
Speaker connectionsXLR / TRS combi input, out / link / thru
Woofer diameter2 x 12 inches
Weight per speaker46 kg
Maximum SPL130 dB – 139 dB
Maximum subwoofer frequency120 Hz
Minimum frequency35 – 39 Hz
RMS power in watts750 – 1,499 W
Locking speaker connectorsno
Weight and dimensions including packaging
Weight (incl. packaging)50.0 kg
Dimensions (incl. packaging)87.5 x 69.5 x 59.0 cm
Product specifications
active 1,200W subwoofer
2x 12-inch
Frequency range (-3 dB): 49 Hz -crossover
frequency range (-10 dB): 39 Hz – crossover
Sensitivity low: 98 dB full-space, 104 dB half-space
Maximum sound pressure at 10% distortion: 132 dB
Maximum sound pressure peak at 10% distortion: 133 dB
Maximum sound pressure in theory: 135 dB
Amplifier: class-D
Amplifier power: 1,200W
Power low: 1,200 watts at 4 ohms
Protected from low power, thermal protection, short-circuit, too much power
Subsonic 24 dB/octave filter peak limiter
Power consumption: 3.3A at 230V
Connectors: 2x XLR in, 2x XLR through, 2x XLR Mix Out
Woofer: 2x 12-inch with 2.5-inch voice coil featuring Advanced Cooling
Built-in crossover: 100 Hz, 120 dB/octave
Built-in stand adapter: M20
4 integrated handles
Housing: birch plywood
Grille: 2mm steel grille
Scratch proof black lacquer
Dimensions: 506 x 806 x 610 mm
Weight: 46.2 kg
HK Audio Linear 5 115 FA protective cover 2x HK Audio Linear 5 115 FA protective cover
The Linear 5 115 FA active speaker cover by HK Audio protects your speaker against dents and bad weather. Rain, careless roadies and reckless driving are far less likely to damage your speaker.
Product features
Suitable for during useno
Speaker protection type15 inch speaker (specific brand/type)
Method of transportnot applicable
Weight and dimensions including packaging
Weight (incl. packaging)800 gr
Dimensions (incl. packaging)70.0 x 48.0 x 6.0 cm
Product specifications
protective cover for the HK Audio Linear 5 115 FA active speaker
protects your speaker against the elements
HK Audio Linear 5 L Sub 2000 (A) cover 4x HK Audio Linear 5 L Sub 2000 (A) cover
The Linear 5L Sub 2000 (A) cover by HK Audio protects your Linear 5 subwoofer against damaging and the elements. It fits both the passive Linear 5L Sub 2000 as the active Linear 5L Sub 2000 A subwoofer.
Product features
CategorySound & PA
Suitable for during useyes
Speaker protection type12 inch subwoofer (specific brand/type)
Method of transportnot applicable
Weight and dimensions including packaging
Weight (incl. packaging)2.0 kg
Dimensions (incl. packaging)80.6 x 61.0 x 50.6 cm
Product specifications
cover for the passive HK Audio Linear 5L Sub 2000 and the active Linear 5 L Sub 2000 A subwoofer
protects your speaker
HK Audio Linear 5 speaker tilt adapter 2x HK Audio Linear 5 speaker tilt adapter
This tilt adapter was designed specifically for HK Audio’s Linear 5 speakers. However, it’ll also fit the L Sub 1200 A, L Sub 2000 and the L Sub 2000 A subwoofers.
Weight and dimensions including packaging
Weight (incl. packaging)100 gr
Dimensions (incl. packaging)20.0 x 3.0 x 3.0 cm
Product specifications
tilt adapter for HK Audio Linear 5 speakers
screws in
weight: 1 kg (15 lbs)
