Description
Specifications
Product features
19-inch rack size 2U
2-ohm compatible yes
Number of amplifier channels 2
Audio loop output yes
Bridge mode yes
Input connector XLR
Built-in filter none
Built-in protectionthermal, peak limiter
Built-in DSP processor yes
Coolingventilator
RMS power (4 ohms) per channel 2100 – 2199 watts
RMS power (8 ohms) per channel 1200 – 1299 watts
Amplifier class AB
Amplifier out putlocking speaker connector, wire clamps
Equipped with crossover yes, fixed
Weight and dimensions including packaging
Weight (incl. packaging)13.2 kg
Dimensions (incl. packaging)56.5 x 56.0 x 18.0 cm
Product specifications
power ful, 2U amplifier
with processor
power at 2 Ohms: 2x 3000 W
power at 4 Ohms: 2x 2100 W (1x 6000 W bridge)
power at 8 Ohms: 2x 1200 W (1x 4200 W bridge)
volume potentiometer per channel
on/off switch
processor menu buttons with LCD
Processing:
input EQ with 6 filters per channel
crossover filters
output EQ with 8 filters per channel
delay function
SubHarmonic Synth: handles the subtones and lowers the sound by an octave
Peak Plus Limiter with threshold, attack and release
30 presets
Indicators:
signal indicator: green LED, 1 per channel
-10dB indicator, green LED, 1 per channel
-20dB indicator, green LED, 1 per channel
ready indicator, green LED, 1 per channel
clip indicator, red LED, 1 per channel
over-heating indicator, red LED, 1 per channel
on/off indicator, blue LED, 1x
Inputs and outputs:
3-pin XLR inputs, balanced, 1 per channel
loop connector for chaining, balanced, 1 per channel
Neutrik SpeakOn NL4MP outputs, 1 per channel
double terminal, 1x per channel
Technical:
signal-to-noise ratio: 103 dB
frequency range: 20 – 20,000 Hz
total harmonic distortion: 500
crosstalk: 20 to 1000 Hz: >70dB
power supply: 100-230 V AC, 50/60 Hz
operating temperature: 0 to 40 degrees Celsius
steel housing
aluminium front panel
fan-cooled, front-to-rear
dimensions: 483 x 89 x 412 mm (19-inch, 2U)
weight: 10.9 kg
