Description
Specifications
Product features
19-inch rack size 2U
Number of channels 1
Digital output no
Energy source AC
Phantom power yes
Phase reverse yes
Feedback dection/eliminator no
Frequency bands per channel 3 – 5 bands
Headphone output no
Built-in compressor yes
Built-in equaliser yes
Built-in limite rno
Connection sockets none
Switchable boost/cut no
Stereo function yes
Analogue audio input type balanced line in (XLR), microphone input (XLR), Hi-Z instrument input (TS jack)
Analogue audio output type balanced line out (XLR)
Type of dynamic processor compressor
Equipped with tube yes
Weight and dimensions including packaging
Weight (incl. packaging)18.0 kg
Dimensions (incl. packaging)58.0 x 47.0 x 21.0 cm
Product specifications
analogue valve mono instrument and microphone preamp
4 dual triode vacuum Sovtek 6922 valves
unbalanced 6.3mm jack instrument input, +30dB
balanced XLR line and microphone input, +30dB
balanced XLR output with trim, -45dB to 20dB gain
input frequency response: -/2.5dB 10Hz to 120kHz
output frequency response: -3dB 1Hz to 200kHz
analogue Vu meter
variable high cut filter from 6dB per octave 30Hz to 140Hz
variable compressor threshold from -30dB to +20dB
variable compressor ratio 1:1 to 20:1
variable compressor attack from 2ms to 200ms
variable compressor release from 100ms to 5sec
4 EQ frequency bands
treble: switching 10kHz, 15kHz, 20kHz, 32kHz, +/- 20dB range
high mid: 200Hz to 2k8Hz and 2kHz to 28kHz, +/- 16dB range
low mid: 30Hz to 450Hz and 300Hz to 4k5Hz, +/- 16dB range
bass: 15Hz, 30Hz, 60Hz, 150Hz, +/- 24dB range
dimensions: 482 x 305 x 89mm (19″, 2U high)
weight: 12 kg
