Allen & Heath SQ5 Digital Mixer

Name: Allen &amp; Heath SQ5 Digital Mixer
SKU: 10329
Price: 2650 EUR
Availability: InStock

Original price was: €3,450.Current price is: €2,650.

For the most demanding audio applications, professional sound engineers count on the SQ-5 digital mixer by Allen & Heath. It boasts the revolutionary XCVI 96kHz FPGA engine, extra-low latency, 16 on-board preamps, 8 stereo FX engines, 12 stereo mixes and more to give you the tools you need for the ultimate live audio experience. These mixes have parametric and graphic EQ, which is ideal for in-ear monitoring. The SQ-5 is compatible with all leading audio network standards so you can provide this mixer with all your apps, expanders, audio networks, personal mixers and more. The integrated SQ-Drive makes it possible to make a 96 kHz multi-track or stereo recording directly.

The Allen & Heath SQ5: “The Sound of Speed”
Allen & Heath’s SQ-5 is engineered to withstand the violence of a live environment. all its functionality is safely contained inside a full-metal chassis. It boasts a rugged, functional construction and looks very impressive and professional as well. The SQ’s dashboard features a 7-inch touch screen surrounded by backlit (rotary)controls that provide visual feedback. on the screen, you can intuitively drag and drop mixes to each strip, which you can then name and assign a colour for an optimal workflow. For FX, the SQ features eight stereo FX engines and a RackExtra library, which consists of a large number of emulations that range from reverbs and delays to modulators and more!

Categories: Digital Mixing Desk, PA Mixers & Mixing Desks, Pro Audio Tag: Allen & Heath

Description

Description

Specifications

Product features
19 inches 19-inch rack mount (not included)
Number of analogue input channels 17 – 24
Number of analogue output channels 9 – 16
Number of channels 129 – 256
Number of microphone inputs 13 – 16
Digital inputsd Snake
Digital snake yes, available separately
Digital outputs AES/EBU (AES3), dSnake
Dynamics compressor, expander, gate
Equalizer 8-band parametric, 15-band, Master EQ
Input connector jack (6.3 mm stereo), Ethernet (RJ45), XLR, XLR AES/EBU
Built-in audio interface USB (multi track), sold separately (via expansion card)
Built-in audio player USB
Built-in effects yes
Insert connectors no
Input level metersvia built-in display, via iPad / iPhone / iPod, via Android Device, via PC/Mac
Remote controlvia iPad, via iPhone, via Android device, via Ethernet
Connector position back
Type of display touch screen, colour
Expansion possibilities DANTE expansion card, expansion card for digitale snake, digitale snake
Output connector jack (6.3 mm), XLR (3-pin)
Mixer power power cable
Volume control knobs, faders, faders + knobs, motorised faders, via PC / Mac, via iPad / iPhone / iPod, via Android, via touchscreen
Weight and dimensions including packaging
Weight (incl. packaging)14.1 kg
Dimensions (incl. packaging)68.0 x 61.0 x 36.0 cm
Product specifications
Allen & Heath SQ-5 digital mixer
96x fader strips (16+1 faders, 6 layers)
16x local mic/line inputs
3x local stereo line inputs
12x XLR + 2x TRS outputs
8x assignable SoftKeys
can be mounted in a 19-inch rack (mounting kit not included)
48x input channels with preamp, HPF, PEQ, gate, comp, delay
32x output channels (LR, 12 mono/stereo Mix, 3 Stereo Matrix)
8x stereo FX with dedicated return channels
8x Mute groups, 8 DCA groups
Source patching (Local, Slink remote, Option card, USB)
output socket & Insert I/O patching
multi-channel USB streaming, direct to USB recording
talkback mic input, dual foot switch control, wireless control
dimensions: 440 x 514.9 x 19.8 mm
weight: 10.5 kg
