19 inches 19-inch rack mount (included)
Control via app yes
Control via PC yes
Number of analogue input channels 9 – 16
Number of analogue output channels 6
Number of speaker processor inputs 10
Number of channels 65 – 128
Number of microphone inputs5 – 8
Number of speaker processor outputs 6
Delay possible yes
Digital inputs AES/EBU (AES3)
Digital snake no
Digital outputs AES/EBU (AES3)
Dynamics compressor, gate, limiter, multiband compressor
Equalizer Master EQ
Input connector 3-pin Euroblock
Built-in audio interface USB (2×2 I/O), Dante
Built-in audio player USB
Built-in effects yes
Insert connector sno
Input level meters via PC/Mac
Remote control via Ethernet, via remote control (available separately)
Connector position back
Type of display LED
Expansion possibilities none
Output connector Ethernet, Euroblock, USB connector
Mixer power power cable
Volume control via PC / Mac
Weight and dimensions including packaging
Weight (incl. packaging)4.8 kg
Dimensions (incl. packaging)50.0 x 30.0 x 10.0 cm
