Description
Specifications
Product features
Speaker connections 6.3 mm TRS input, XLR input, XLR / TRS combi input, out / link / thru
Woofer diameter 18 inches
Weight per speaker 52 kg
Maximum SPL 130 dB – 139 dB
Maximum subwoofer frequency 180 Hz
Minimum frequency 25 – 29 Hz
RMS power in watts 1,500 – 3,000 W
Locking speaker connectors no
Weight and dimensions including packaging
Weight (incl. packaging)59.0 kg
Dimensions (incl. packaging)93.0 x 71.5 x 60.8 cm
Product specifications
Electro-Voice ELX200-18SP
Active Subwoofer
built-in DSP and LCD display
connections:
inputs:: 2x XLR/TRS combo
outputs: 2x XLR link output
technical information:
woofer: 18 inch DVX woofer
frequency response: 33 – 150 Hz
frequency range: 28Hz – 180Hz
max. SPL: 135dB
power output: 1800 W
adjustable low-pass frequency: 80, 100, 120 or 150 Hz
speaker cabinet:
2x metal handles
35mm stand flange
8x M10 rubber feet
removable wheels
18mm-thick 3-ply birch construction with EV coating
16AWG metal grille with powdered coating
dimensions (without legs): 67.5 x 91 x 55cm (W x D x H)
weight: 51.8 kg
