Description
Specifications
Product features
19-inch rack size not applicable
Number of keys 73
Arpeggiator/sequencer arpeggiator
Computer integration none
Control sustain (input), expression (input), ribbon, aftertouch
Synthesizer inputs none
Sound sourcedi gital
MIDI & CV/gate MIDI in, MIDI out, MIDI thru, MIDI over USB, CV/gate in, CV/gate out
Synthesizer outputs line out jack, headphone
Type of key skeyboard action
Synthesizer type keyboard
Power adapter ungrounded flat Europlug
Weight and dimensions including packaging
Weight (incl. packaging)0 gr
Product specifications
ASM Hydrasynth Deluxe
synthesizer
polyphonic aftertouch
polyphony: 16
sound generator: 3x wavescan (219 waves), 4x mutator (8 types), noise (7 types)
mutators: FM-Lin, WaveStack, PW-Orig, PW-Squeeze, PW-ASM, Harmonic Sweep, Hard Sync, PhazDiff
noise: White, Pink, Brown, Red, Blue, Violet, Grey
LFO: 5x per voice with tempo-synch and semitone-lock: Sine, Triangle, Saw Up, Saw Down, Square, Pulse27%, Pulse13%, S&H, Noise, Random, Step
envelopes: 5x per voice, tempo-sync, variable trigger source
filters: 1x multimode + 1x LP-band/notch-HP
multimode-filters: LP Ldr12, LP Ldr24, LP Fat12, LP Fat24, LP Gate, LP MS20, HP MS20, LP 3-Ler, BP 3-Ler, HP 3-Ler, LP Stn12, BP Stn12, HP Stn12, LP 1 Pole, LP 8 Pole, Vowel
effects:
9x insert
5x delay
4x reverb
modulation matrix (32 slots)
8x macro-controllers
MPE-compatible
micro-tuning
dimensions: 1129 x 346 x 92mm
weight: 13.3 kg
