Description
Specifications
Product features
19-inch rack size 3U
2-ohm compatible yes
Number of amplifier channels 2
Audio loop output no
Bridge mode yes
Input connectorj ack (6.3 mm), XLR
Built-in filter HPF
Built-in protection peak limiter, clip indicator
Built-in DSP processor no
Cooling ventilator
RMS power (4 ohms) per channel 1800 – 1899 watts
RMS power (8 ohms) per channel 1000 – 1099 watts
Amplifier class H
Amplifier outputlocking speaker connector
Equipped with crossover yes, fixed
Weight and dimensions including packaging
Weight (incl. packaging)38.0 kg
Dimensions (incl. packaging)61.0 x 55.9 x 22.9 cm
Product specifications
PA amplifier
power capacity:
2x 1050 Watts @ 8 Ohms stereo
2x 1800 Watts @ 4 Ohms stereo
1x 3600 Watts @ 8 Ohms bridged
1x 5000 Watts @ 4 Ohms bridged
frequency response: 20 Hz to 20 kHz
connectors:
2x XLR input
2x TRS jack input
2x SpeakOn output
4x double terminal
controllers:
volume (L/R individually adjustable)
on/off switch
mode adjustable via dip switch
Class-H
rack: 19-inch, 3 U
dimensions: 133 x 482 x 404 mm
weight: 33.1 kg
