Description
Specifications
Product features
Number of keys 88
Drawbar function no
Weight 15 – 19.9 kg
Includes chassis no
Includes pedals yes, 1
Built-in amplifier not applicable
Colour housing black
MIDI I/Oin/out
Pitch and modulation wheel yes
Polyphony (max.)128
Sequencer / recorder yes
Type of display LCD, monochrome
Keyboard type hammer action
Weight and dimensions including packaging
Weight (incl. packaging)20.0 kg
Dimensions (incl. packaging)150.0 x 45.0 x 25.0 cm
Product specifications
stage piano
keyboard
88 keys
natural wood, graded hammer, with synthetic ebony and ivory surface
sound generators: AWM2
polyphony: 128
sounds: 57 (10 piano, 14 electric pianos and 33 sub voices)
live set sounds: 160, 80 presets
effects
Piano 2 system: 5
E.PIANO3 system: 13
SUB 1 system: 5
delay: analogue and digital
reverb
controllers
2x part level encoder
4x EQ/FX encoder
data entry/song level encoder
modulation wheels: 2
master volume
LCD display: 128 x 64 pixels
connectors:
main out L/mono, R (jack, unbalanced)
XLR out L, R (balanced)
input L/mono, R (jack, standard mono)
2x pedal: sustain/assignable, jack
2x foot controller, jack
MIDI in/out
USB to host
USB to device
headphones: stereo jack
AC adapter connection
LCD display (128 x 64)
includes sustain pedal (FC3A)
aluminium housing
dimensions: 1298 x 364 x 141
weight: 18.6 kg
